BactoBox®

BactoBox®

Refers to either a BactoBox® device or a BactoBox® setup. Use "BactoBox®" when the context doesn't require further explanation.

BactoBox® device

The 240×140×60 mm device itself. References just the device and no consumables or accessories.

Item numbers

Breakdown

Front view

Right view

Left view

Symbol

Explanation

A

Flow cell cover. The flow cell compartment is underneath.

B

Display

C

Measure button. Press to start a measurement. Long press to enter the programs menu.

D

Stop button. Press to stop the the current program. Long press to enter the menu.

E

Empty button. Press to run the empty the flow paths.

F

Clean button. Press to clean the flow paths. Use a disinfection vial.

Symbol

Explanation

G

USB port

H

LED power-indicator

I

Power plug

J

On/off rocker switch

Symbol

Explanation

K

Inlet. White color. Uses a Luer lock connector.

L

Outlet. Black color. Uses a Luer lock connector.

Flow cell compartment

The space just under the flow cell cover. This is where we put the flow cell. The flow cell compartment reveals the PCB including electrical pogo pins and the inlet/outlet for the liquid. Both the electrical and liquid pathways are very delicate, which is why we protect them with the flow cell cover against dust, spills, etc.

BactoBox® setup

The combination of several items: A BactoBox® device, its consumables, and its accessories. Together, these items form a BactoBox® setup.

The usual setup items are:

• BactoBox® device

• flow cell

• flow cell cover

• power supply

• vial rack

• tubing kit

• external filter

• inlet-outlet cover

This list may change as we add/change the available consumables and accessories.
